[:en]Camera
Image Sensor: 1/1.8″ Progressive Scan CMOS
Min. Illumination: Color: 0.002 Lux @ (F1.2, AGC ON); 0.031 Lux @ (F1.5, AGC ON), 0 Lux with white light on
Shutter Speed: 1 s to 1/100,000 s
Slow Shutter: Yes
Auto-Iris: DC drive
Day & Night: IR Cut Filter
DNR: 3D DNR
WDR: 120 dB
Lens
Focal Length: 2.8 to 12 mm 8 to 32 mm
Aperture Range: 2.8 to 12 mm: F1.5 – 2.8 8 to 32 mm: F1.6
FOV: 2.8 to 12 mm: horizontal FOV 81.8° to 31.2°, vertical FOV: 43.5° to 17.6°, diagonal FOV: 97° to 36.3° 8 to 32 mm: horizontal FOV 42° to 13.2°, vertical FOV: 23.6° to 7.8°, diagonal FOV: 49° to 15.5°
Decoding
Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate: 64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Video
Max. Resolution: 1920 × 1080
H.265+: Main stream supports
H.264 Type: Baseline Profile/Main Profile/High Profile
H.265 Type: Main Profile
H.264+: Main stream supports
Audio
Environment Noise Filtering: Yes
Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Smart Feature-Set
Face Detection: Yes
Behavior Analysis: Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection
Region Of Interest: Support 4 fixed regions for each stream, and dynamic tracking
Exception Detection: Scene change detection, audio exception detection
Exception: Audio exception detection
Target Cropping: Yes
Image Enhancement: BLC, defog, EIS, 3D DNR, HLC
Image Settings: Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser
SVC: Yes
Day/Night Switch: Auto/Schedule/Day/Night/Triggered by Alarm In
Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Main Stream: 50Hz: 50fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub Stream: 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Third Stream: 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream: 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Fifth Stream: 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Network
Network Storage: Support Micro SD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR
Alarm Trigger: Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
API: ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Simultaneous Live View: Up to 20 channels
User/Host: Up to 32 users. 3 user levels: Administrator, Operator and User
Web Browser: IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
General Function: One-key reset, anti-flicker, five streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Interface
Communication Interface: 1 RJ45 10M/100M/1000M self-adaptive Ethernet port, 1 RS-485 interface
Video Output: 1Vp-p composite output (75 Ω/BNC)
On-Board Storage: Built-in micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button: Yes
Audio: I/O1-ch 3.5 mm audio input (line in), 1-ch 3.5 mm audio output (line out), mono sound
Alarm: I/O2 inputs, 2 outputs (up to 24 VDC 1 A or 110 VAC 500 mA)
General
Firmware Version: V5.4.7
Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F) Humidity 95% or less (non-condensing)
Power Supply: 36 VDC, three-core terminal block
Power Consumption And Current: 36 VDC, 1 A, max. 35 W
Weight: Camera: approx. 6 kg (13.2 lb.) With Package: approx. 8 kg (17.6 lb.)
Protection Level: IP67, IK10 (camera body)
Shell Material: Aluminum alloy
Dimensions (W × D × H): 560 × 339 × 160 mm (22.0″ × 13.3″ × 6.3″)
IR
IR Range: Up to 100 m
IR Wave: length850nm
Compression
Video Compression: Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG Third stream: H.265/H.264 Fourth stream: H.265/H.264 Fifth stream: H.265/H.264
Video Bit Rate: 32 Kbps to 16 Mbps
Road Traffic And Vehicle Detection
Accuracy: Capture Rate > 99%, accuracy rate > 98% when only one lane is configured
Vehicle Speed: Support vehicle speed under 120 km/h (74.6 mi/h)
Line Number: 2 lanes
Direction: Support capture and recognition of vehicles both approaching and leaving
Whitelist And Blacklist: Up to 10000
Smart Feature-Set
Recognition: License Plate Recognition[:zh]
