CNB NP25-6P3R PTZ Camera

– Multi-Codec (H.265/H.264/MJPEG)
– Full HD Progressive scan CMOS
– 3x Motorized Focus & Zoom Lens
– Remote Pan/Tilt/Zoom Control
– Multi profile streaming
– (4 different streams per Resolution, Frame, Rate, Codec)
– Built-in standard PoE
– Two-way audio communication
– Built-in D/N (TDN), IR LED
– Compact design & Easy installation
– Vandal proof, Weather proof (IP66)

描述

ModelNP25-6P3R
..[Camera]
Image Sensor1/3 Inch Progressive scan 2Mega CMOS
Effective Pixels1944 X1092 pixels
Scanning SystemProgressive scan
S/N RatioMore than 50dB(AGC Off)
Lens2.8 ~ 12mm Motorized Vari-focal(F 1.4)
Angular of ViewDiagonal 120.8˚(W)~ 36˚(T)
IR LedHigh Power Led 10ea(850nm, 50˚)
Min illumination0.05Lux (Color), 0 Lux (IR LED On)
Panning/Tilting RatioPan: 0˚ ~ 356˚ ; Tilt : 26˚ ~ 90˚
..[Function]
AGCAuto
FlickerlessOn/Off
Shutter speedMax. 1/30,000
White BalanceAWB
Backlight CompensationDWDR
WDR Range70dB
DNR2DNR , 3DNR Supported
Day & NightAuto(ICR), IR LED
PRIVACY1 Supported
Anti-fogSupported (5 Step)
Factory resetSupported
..[Interface]
LANRJ-45(10/100BaseT), Auto MDIX
Analog Video1ch D1 CVBS Output
Alarm1 Sensor input, 1 Relay output
Audio1 Mic Line input, 1 Line Output
..[Network]
Video CompressionMulti-Coded(H.265 / H.264 / MJPEG)
Max Resolution1920 x 1080@60fps
Multi-Profile Streaming4 simultaneous video profiles
Intelligent Bit-Rate ControlVBR, CBR
Motion detection3 regions
Audio CommunicationTwo-way Communication
Mono Upstream32Kbps G.726 ADPCM
64Kbps 16bit μ-law PCM (MIC / Line-in)
Mono Downstream64Kbps G.71116bit μ-law PCM(Line-out)
IP(Internet Protocol)IPv4
Network ProtocolIPv4, TCP, UDP, IGMP, ICMP, ARP, RARP, PPPoE, RTCP, RTP, RTSP, SDP, HTTP, HTTPS, SMTP, FTP, DHCP, UPnP, NTP, DNS, DynDNS
Dynamic IPSupport
Security-User ID & Password protection
-IP address filtering-Digest Authentication
User Access Log
Streaming method-RTSP streaming with proprietary formatfor control informations
-Standard RTSP streaming
-HTTP streaming
-Onvif Profile-S
Intelligent VideoMotion Detection
AlarmTriggersIntelligent Video + Sensor Input
Alarm EventsVideo file upload(FTP), Still Image(Email), Relay output
Alarm Buffer(Audio/Video)configurable Pre-alarm (5~15 sec) & Post-alarm (10~60 sec)
Client SoftwareNVR2, Smart App(Android, iOS)
..[General]
Operating Temperature-10℃~ 50℃
Operating Humidity0 ~ 80% RH
PowerDC12V, Max. 0.6A, IEEE802.3af PoE
Dimensions (Øx H)Ø134 x 119mm
Material / IP RatioAL, PC / IP66
WeightApprox. 750g
