DrayTek Vigor C410 Series
4G Cellular VPN Security Router
Features
- Embedded SIM Slot
- Firewall & Content Filter
- VPN (Virtual Private Network)
- URL/IP Reputation
- EasyVPN
- Hotspot Web Portal
- IAM
- Virtual AP/Switch controller
- Bandwidth Management
- Mesh (Wireless model only)
- DrayDDNS
Specifications
| Performance | |
| NAT Session | 50K |
| Max. NAT (Mbps) | 940 |
| WAN | |
| Ethernet (1 GbE) | 2 |
| Ethernet – LAN/WAN Switchable | √ |
| Cellular (Built-in) | 4G |
| Networking | |
| Routing |
IPv4 Static Route
IPv6 Static Route
Policy Route
Inter-VLAN Route
RIP v1/v2
OSPF(V2/V3)
BGP
|
| Policy-based Routing |
Protocol
IP Address
Port
|
| DNS Security (DNSSEC) | √ |
| IGMP |
IGMP v2/v3
IGMP Proxy
IGMP Snooping & Fast Leave
|
| Local RADIUS server | √ |
| Physical | |
| Power Input | Vigor C410: DC 12V @ 0.7A Vigor C410ax: DC 12V @ 1.4A |
| Max. Power Consumption (watts) |
Vigor C410: 8.3
Vigor C410ax: 16.2
|
| Dimension (mm) | 207 x 131 x 42 |
| Operating Temperature | 0 to 45°C |
| Storage Temperature | -25 to 70°C |
| Operating Humidity (non-condensing) | 10 to 90% |
