描述
POWERCOM-VGS-L
VGSL – Vanguard II ON – Line UPS
POWERCOM-VGS-L 屬POWERCOM不斷電系統（UPS）產品。傑成系統有限公司（香港防盜）為POWERCOM產品安裝商及經銷商，可提供供應、安裝、調試、保養及維修。UPS 可為閉路電視錄影機、門禁控制器、網絡設備及伺服器提供後備電源，方案可參考Server Room 架設及維修。規格以原廠資料為準。
產品說明
POWERCOM VGS-L online series with high performance power output and curve shape outfit is the best choice for business, IT and Telecom system. High performance VGS-L series power factor 0.9 and attached with PFC (Power Factor Correction) stabilize fluctuate voltage, including over voltage, lower voltage and provide clean and stable voltage for critical device. POWERCOM VGS-L series applied long-backup operating design, supports extra-long backup time for your critical device. POWERCOM VGS-L online series with easy-reading LCD indicator, clearly shows up UPS status and easy to operate. VGS-L series attach with selectable mode offers different application for user, such as high efficiency mode, free run mode.
- Extendable long backup time for devices
- Pure Sinewave with Double Conversion
- Designed for Advanced Electronic Device
- High Efficiency and Free-Run Mode Available
- Overload, Surge, Short Circuit Protection
- VGSL-1000 / 1500 / 2000 / 3000 / 6000 / 10KVA
型號：VGS-1000-L、VGS-1500-L、VGS-2000-L、VGS-3000-L、VGS-6000-L、VGS-10000-L
規格
| UPS | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Model | VGS-1000-L | VGS-1500-L | VGS-2000-L | VGS-3000-L | VGS-6000-L | VGS-10000-L | |||
| Capacity (VA) | 1000 | 1500 | 2000 | 3000 | 6000 | 10000 | |||
| Capacity (Watts) | 900 | 1350 | 1800 | 2700 | 5400 | 9000 | |||
| Form | Tower | ||||||||
| Phase | Single Phase | ||||||||
| Energy Saving | Yes – ECO mode Efficiency > 94% | INPUT | |||||||
| Voltage | 220 / 230 / 240 Vac | ||||||||
| Voltage Range | 120 ~ 276 Vac < 25% Load 140 ~ 276 Vac < 50% Load 160 ~ 276 Vac < 75% Load 180 ~ 276 Vac < 100% Load | ||||||||
| Frequency Range | 50 / 60Hz ±2.5Hz auto sensing (45 to 65Hz user selectable) | ||||||||
| Power Factor | > 0.97 | ||||||||
| Cold Start | Yes | OUTPUT | |||||||
| Rated Power Factor | 0.9 | ||||||||
| Waveform | Pure Sine Wave | ||||||||
| Voltage | 208 / 220 / 230 / 240 Vac ±2% (selectable output voltage) | ||||||||
| Frequency | 50 / 60 Hz ±0.25 Hz | ||||||||
| Transfer Time | 0 ms | ||||||||
| Harmonic Distortion | < 5% of T.H.D. at non-Linear Load < 2.5% of T.H.D. at Linear Load |
< 5% of T.H.D. at non-Linear Load < 3% of T.H.D. at Linear Load |
|||||||
| Efficieny | Approximately 89% | ||||||||
| Connections | *Please refer below “Receptacle Options” Customized receptacle can be discussed |
||||||||
| Crest Factor | 3 : 1 | ||||||||
| EPO Function | Yes | PROTECTION | |||||||
| Overload | Line Mode | 106% – 120% for 30 seconds 121% – 150% for 10 seconds | |||||||
| Battery Mode | 101% – 109% for 10 seconds 110% – 120% for 3 seconds | ||||||||
| Surge Protection | IEC 61000-4-5 Level 3 | ||||||||
| Bypass | Internal Bypass(Automatic and Manual) | ||||||||
| Short Circuit Protection | UPS output cut off immediately or protected by input fuse or circuit breaker | ||||||||
| Overload Protection | UPS automatic power off if overload exceeds 106% to 120% of nominal at 30 seconds; 121% to 150% for 10 seconds; |
||||||||
| Tele-Comunication | RJ45 x 2 | ||||||||
| Alarm | Buzzer beeps under backup mode, battery low, battery charging fault, and overload | CHARGER | |||||||
| UPS | 1A | ||||||||
| UPS Build In | 5A | 4A | |||||||
| Total | 6A | 5A | BATTERY | ||||||
| Model | VGS-1000-L | VGS-1500-L | VGS-2000-L | VGS-3000-L | VGS-6000-L | VGS-10000-L | |||
| Voltage | 36V | 48V | 72V | 96V | 240V | MANAGEMENT | |||
| Indicator | LCD/LED Control Panel | ||||||||
| Communication Port | RS232, USB(B-type) | ||||||||
| SNMP Slot | Option | ||||||||
| Audible Alarms | YES | PHYSICAL | |||||||
| Dimensions (WxDxH)(mm) | 152 x 420 x 237 | 152 x 500 x 241 | 225 x 420 x 358 | 257 x 590 x 570 | 257 x 650 x 585 | ||||
| Weights (Kgs) | 7.7 | 10.1 | 12.7 | 13.2 | 38 | 46 | |||
| Shipping Dimensions (WxDxH) | 280 x 545 x 355 | 280 x 625 x 356 | 340 x 526 x 485 | 415 x 760 x 800 | 408 x 860 x 800 | ||||
| Shipping Weights (Kgs) | 9.8 | 12 | 15.5 | 16.3 | 58 | 61.6 | |||
