ROSSLARE AYC-Q65
Convertible Anti-Vandal Piezoelectric 3×4 Proximity & PIN Reader/Controller
MAIN FEATURES
Supports 4- to 8-digit PIN credentials and 125 kHz EM type RFID cards and tags
Smooth, attractive design, with all-weather indoor and outdoor operation
Large, highly-visible piezoelectric keypad
2 tri-colored LEDs and an integral sounder for programming and operation
User-friendly menu, based on LED and sounder indicators
Back and cover optical tamper detection and output
Multi-format reader (Wiegand 26-Bit/Clock & Data/Card & PIN)
Automatically recognizes Rosslare’s PS-x25T intelligent power supply family converting it into a 500-user standalone controller with secure relays
PROFESSIONAL GRADE FEATURES
9 selectable PIN transmission modes including options for Key Stream, Binary, Parity, and 3×4 Matrix
Comes with a mounting and drilling label, security screw, and tool set to prevent unauthorized opening
60 cm (23.6 in.) shielded interface cable
SPECIFICATIONS
| ELECTRICAL SPECIFICATIONS | |
| Operating Voltage Range | Reader mode: 5 to 16 VDC from a standard controller Controller mode: PS-x25T series intelligent power supplies |
| Input Current | Standby: 90 mA at 12 VDC ; Maximum: 130 mA at 16 VDC |
| Proximity Card Reader | Maximum read range*: 45 mm (1.77 in.) Modulation: ASK at 125 kHz Compatible cards: EM cards |
| Tamper | Optical back tamper sensor, O.C. active low, 30 mA max. sink current |
| OPERATIONAL SPECIFICATIONS | |
| Keypad | 3×4 keypad for local programming and 4- to 8-digit PIN codes entry |
| Design | Epoxy-potted, fully-sealed in a rugged metal enclosure, metal piezoelectric keypad, highly strong construction. Suitable for extremely harsh environments |
| Audio/Visual | 2 tri-color LED indicators, built-in buzzer |
| READER MODE | |
| LED Control | Dry contact, N.O. |
| Facility Code | Programmable |
| Read Card Format | Selectable Wiegand 26-Bit, Clock & Data, Card & PIN |
| PIN Code Formats | 9 selectable formats, from 4- to 8-digit length PIN codes |
| CONTROLLER MODE | (available with PS-x25T series intelligent power supplies only) |
| Capacity | 500 users, dual code/card or code + card each |
| User Levels | Normal, Secure, Master |
| Security Modes | Normal, Bypass, Secure |
| Outputs | Lock Strike output ; Auxiliary output (PS-x25T series) |
| Inputs | REX (Request-to-Exit) Auxiliary/door monitor with 10 programmable modes |
| ENVIRONMENTAL SPECIFICATIONS | |
| Operating Environment | All weather, indoor and outdoor use, meets IP65 |
| Operating Temperature | -35°C to 66°C (-31°F to 151°F) |
| Operating Humidity | 0 to 95% |
| PHYSICAL SPECIFICATIONS | |
| Dimensions | 120 x 76 x 21 mm (4.72 x 3 x 0.83 in.) |
| Weight | 480 g (1.05 lb) |
